NHP 6 Amp MOD6+ MCB/RCD RCBO C Curve 1 Pole + Neutral 6kA 30mA Type A (2 Screw)

The NHP 6 Amp MOD6+ MCB/RCD RCBO (Residual Current Breaker with Overcurrent Protection) provides reliable protection against both overload and earth leakage faults. Featuring a 1 Pole + Neutral configuration, this device offers 30mA Type A sensitivity for detecting leakage currents, while the C Curve trip characteristic ensures effective protection for inductive loads. With a 6kA short-circuit rating, it guarantees high performance and safety in both residential and commercial electrical systems. The 2-screw design allows for secure and simple installation. The MOD6+ range of miniature circuit breakers (MCBs) is designed to offer cost-effective solutions for electrical protection, with a proven history of performance and safety.
Key Features:
6 Amp current rating for reliable protection in low to medium power circuits.
1 Pole + Neutral configuration for efficient overload and leakage current protection.
30mA Type A sensitivity for reliable detection of leakage faults.
C Curve trip characteristic ideal for inductive loads.
6kA short-circuit rating for enhanced safety and protection.
Easy installation with a 2-screw design for secure mounting.
Part of NHP’s MOD6+ range, offering miniature circuit breakers (MCBs) for overload and short circuit protection.
Available in current ratings from 6-63A, with 1P, 2P, or 3P options and a C trip curve.
Cost-effective solution for both residential and commercial applications.
Warranty Information
Warranty Method
Return to ALL LED DIRECT
Commercial Use
1 Year
Domestic Use
1 Year
Warranty Period
1 Year
Attributes
Brand
NHP
Part Number
MD6RD0630A
Amperage Range
6 Amps
Max Cable Size
25mmSq
Number Of DIN Modules
Poles
1 Pole + N
Standard
Sub Category
MC

Attributes:

Brand: NHP
Part Number: MD6RD0630A
Amperage Range: 6 Amps
Max Cable Size: 25mmSq
Poles: 1 Pole + N
Sub Category: MCB & RCD RCBO Combos
Breaking Capacity: 6 kA
Trip Curve: C Curve
Type: Type A
Voltage: 240 Volts
Freight Levy: Freight Free on ALL LED DIRECT Couriers for orders over $500
Weight (kg): 0.1200
Length (mm): 76
Height (mm): 86
Width (mm): 18
Length Packaging (mm): 103
Height Packaging (mm): 20
Width Packaging (mm): 75
