NHP 50 Amp DIN-T Miniature Circuit Breaker MCB C Curve 1 Pole 10kA

NHP DIN-T Miniature Circuit Breakers (MCB) are highperformance electrical protection devices offering a comprehensive range of features to meet the needs of any project. These MCBs are available in short circuit ratings of 6kA and 10kA with current ratings from 0.5A through to 125A in variety of B, C or D trip curves. These MCBs are available in 1P, 2P, 3P and 4P housings
Warranty Information
Warranty Method
Return to ALL LED DIRECT
Commercial Use
1 Year
Domestic Use
1 Year
Warranty Period
1 Year
Attributes
Brand
NHP
Part Number
DTM10150C
Amperage Range
50 Amps
Max Cable Size
Poles
1 Pole
Standard
Sub Category
Circuit Breakers A/C
Breaking Capacity
10 kA
Trip Curve
C Curve
Voltage
240 Volts
Weight (kg)
0.1200
Length (mm)
75
Height (mm)
85
Width (mm)
18
Length Packaging (mm)
75
Height Packaging (mm)
85
Width Packaging (mm)
18
Barcode
2000101057062
Barcode (Secondary)
4053546127683
Tech Data Sheets
DTM10150C - Tech Data Sheet
Download
