NHP 25 Amp MOD6+ MCB/RCD RCBO C Curve 3 Pole + Neutral 30mA 6kA Type A

The NHP 25 Amp MOD6+ MCB/RCD RCBO (Residual Current Breaker with Overcurrent Protection) provides comprehensive protection against both overloads and leakage currents in three-phase electrical systems. Featuring a 3 Pole + Neutral configuration, this device offers 30mA Type A sensitivity, ensuring reliable detection of leakage faults. The C Curve trip characteristic is ideal for circuits with inductive loads, such as motors. With a 6kA short-circuit rating, this RCBO ensures high protection and safety. Part of the MOD6+ range, it is designed for easy installation and robust performance in both residential and commercial applications, making it a dependable solution for effective circuit protection.
Key Features:
25 Amp current rating for reliable protection in three-phase circuits.
3 Pole + Neutral configuration for efficient overload and leakage fault protection.
30mA Type A sensitivity for reliable detection of leakage currents.
C Curve trip characteristic, perfect for inductive loads like motors.
6kA short-circuit rating for high-level protection and safety.
Ideal for both residential and commercial electrical systems.
Part of NHP’s MOD6+ range, providing robust protection against overloads and leakage faults.
Easy to install and designed for long-lasting performance.
Warranty Information
Warranty Method
Return to ALL LED DIRECT
Commercial Use
1 Year
Domestic Use
1 Year
Warranty Period
1 Year
Attributes
Brand
NHP
Part Number
MD6R42530A
Amperage Range
25 Amps
Max Cable Size
Number Of DIN Modules
3 Module
Poles
3 Pole + N
Standard
Sub Category
MCB/RCD RCBO Combos
Breaking Capacity
6 kA
Trip Curve
C Curve

Attributes:

Brand: NHP
Part Number: MD6R42530A
Amperage Range: 25 Amps
Number Of DIN Modules: 3 Module
Poles: 3 Pole + N
Sub Category: MCB/RCD RCBO Combos
Breaking Capacity: 6 kA
Trip Curve: C Curve
Type: Type A
Voltage: 415 Volts
Freight Levy: Freight Free on ALL LED DIRECT Couriers for orders over $500
Weight (kg): 0.0000
Length (mm): 71
Height (mm): 75
Width (mm): 72
Length Packaging (mm): 71
Height Packaging (mm): 75
Width Packaging (mm): 72
Barcode: 2000101031956
