NHP 10 Amp DIN-T Miniature Circuit Breaker MCB C Curve 1 Pole 6kA

NHP DIN-T Miniature Circuit Breakers (MCB) are highperformance electrical protection devices offering a comprehensive range of features to meet the needs of any project. These MCBs are available in short circuit ratings of 6kA and 10kA with current ratings from 0.5A through to 125A in varity of B, C or D trip curves. These MCBs are available in 1P, 2P, 3P and 4P housings
Warranty Information
Warranty Method
Return to ALL LED DIRECT
Commercial Use
1 Year
Domestic Use
1 Year
Warranty Period
1 Year
Attributes
Brand
NHP
Part Number
DTM6110C
Also Known As
DTCB6110C
Amperage Range
10 Amps
Max Cable Size
35mmSq
Poles
1 Pole
Standard
Sub Category
MCB & RCD RCBO Combos
Breaking Capacity
6 kA
Trip Curve
C Curve
Voltage
240 Volts
Weight (kg)
0.0000
Length (mm)
75
Height (mm)
85
Width (mm)
18
Length Packaging (mm)
75
Height Packaging (mm)
85
Width Packaging (mm)
18
Barcode
2000101049692
Barcode (Secondary)
4053546126518
Barcode (Tertiary)
4053546129014
Tech Data Sheets
DTM6110C - Tech Data Sheet
Download
