Hazardous Location Flood Light L1719 SMD

Light Features

• Smaller volume and lighter weight compare to similar products.
• Energy consumption is at least 50% less than traditional HID light sources.
• Reduced maintenance and improved light quality.
• Separate wiring compartment for easy connection.

Applicable Location

• Zone 2
• Zone 21 & 22
• Class I, Division 2 (Groups A, B, C and D)

Protection

Degree of Protection - IP67 / NEMA 6

UL Certification

• UL844 - Class I, Division 2 (Groups A, B, C and D)
• UL1598

IECEx Certification

• Ex nR IIC T4...T5 Gc
• Ex tb IIIC T120°C...T95°C Db

ATEX Certification

• II 3 G Ex nR IIC T4...T5 Gc
• II 2 D Ex tb IIIC T120°C...T95°C Db

Specification

• Volt.: 100V / 110V / 120V / 200V / 220V / 230V / 277V / 347V / 480V AC
• Watt.: Rectangular SMD-300W, Round SMD-240W / 280W / 300W
• Amps: 240W (0.50A~2.40A) / 280W (0.58A~2.80A) / 300W (0.63A~3.00A)

• Frequency: 50Hz / 60Hz
• Power Factor: cos≧0.9

Ambient temprature

• -40°C ~ +55°C, T4 / -40°C ~ +65°C, T3C

Optical Information

• CCT : 3000K (Warm White) / 5000K (Cool White)
• CRI : Warm White≧80 / Cool White≧70
• Lum/Watt. : ≧ 100 (Warm White) / ≧ 110 (Cool White)
• Beam Angle : X-110° / Y-110°
