Electra 1mm 2 Core Fire Control Cable Red & White With Red Sheathing 500 Metre Drum

Key Features
Application: Suitable for fire alarms, smoke detectors, speakers, modules, evacuation systems, 24VDC power, and ancillaries
Conductor: Plain annealed copper for optimal conductivity
Insulation Material: PVC V75 or low smoke zero halogen for enhanced safety
Sheath Material: PVC V75 or low smoke zero halogen for durability
Sheath Colour: Red (optional red or yellow trace/stripes for visibility)
Standards Compliance: AS/NZS 3013:2005 (WSX1 – Mechanical), AS/NZS 1125, IEC 60228, AS/NZS 3808, AS/NZS 5000.2, AS 1670:2018 ELV Markings, AS/ACIF S008 ACMA Compliance
Greenstar: Approved for sustainability and safety
Main Benefits
Enhanced Safety: Compliant with multiple industry standards, guaranteeing safety and performance in fire protection applications
Convenient Installation: Supplied on a 500 metre drum for extensive installations, reducing the need for multiple cable joins
Durable Construction: Features plain annealed copper conductors and durable red sheathing for long-lasting performance
Flexible Options: Available with optional trace or stripes in red or yellow for visibility and identification
Install fire protection systems with the Electra 1mm

Attributes:

Brand: Electra Cables
Part Number: FC7402-LD-500
Also Known As: 2c Twin core
Cable Conductor Material: Annealed Copper
Cable Core Colours: Red & White
Cable Drum Length: 500 Metres
Cable Insulation & Sheath Material: PVC
Cable Sheath Colour: Red
Cable Size mm: 1mm
Cable Voltage: 250 Volts Light Duty
Number of Cores: 2
Sub Category: Fire Rated Cable
Freight Levy: Freight Free on ALL LED DIRECT Couriers for orders over $500
Weight (kg): 27.7000
Length (mm): 290
Height (mm): 290
Width (mm): 300
Length Packaging (mm): 290
Height Packaging (mm): 290
Width Packaging (mm): 300
Barcode: 2000100834008
Barcode (Secondary): 9318229015295

Warranty Information:

Warranty Method
Return to ALL LED DIRECT
Commercial Use
1 Year
Domestic Use
1 Year
Warranty Period
1 Year
