CBI Heinemann 10 Amp MCB/RCD RCBO C Curve 1 Pole + Neutral SF1 30mA 6kA

Single Pole hydraulic-magnetic RCBO
Provides 30mA residual current protection
Complies with AS/NZS 3190 (Approval Number NSW21007)
Switches both the Active and Neutral Poles
Overcurrent trip point unaffected by ambient temperature
Operating voltage: 240Vac (50Hz/60Hz)
Immune to pulsating DC
IP2X Shrouded line and load terminals
Warranty Information
Warranty Method
Return to ALL LED DIRECT
Commercial Use
1 Year
Domestic Use
1 Year
Warranty Period
1 Year
Attributes
Brand
CBI Heinemann
Part Number
SF1EL10-3
Also Known As
RCCB
Residual Circuit Breaker
Residual Circuit Breakers
GFCI
GFI
ALCI
RCD
Safety Switch
Safety Switches
Miniature Circuit Breaker
Residual Current Device
Amperage Range
10 Amps
Max Cable Size
Number Of DIN Modules
1 Module
Poles
1 Pole + N
Standard
Sub Category
MCB/RCD RCBO Combos
Breaking Capacity
6 kA
Trip Curve
C Curve
Type
Type A
Voltage
240 Volts
Weight (kg)
0.3630
Length Packaging (mm)
30
Height Packaging (mm)
190
Width Packaging (mm)
80
Barcode
6009522903398
Tech Data Sheets
SF1EL10-3 - Tech Data Sheet
Download
