Cabac 5 Amp 3 Wire Hourly Mech Timer Switch 240 Volts

Cabac 5 Amp 3 Wire Hourly Mech Timer Switch 240 Volts

$124.34 AUD
$124.34 AUD $124.34 AUD
Sale Sold out
Tax included.

he S-Click HNS450TM is a 3-wire hour time switch that provides convenient, timed operation of fans, motors and lighting. Time delay can be set in hour increments from 1 to 24 hours-perfect for garden lighting, water features and other applications requiring an extended run time. Alternatively, a quick tap will cancel the timer program and turn power off.

An amber LED indicates device status and gives an expiry warning before time-out. The timer settings are retained even after loss of power and can be configured to power up on or off after loss of mains power.

Programming your chosen off time couldn't be simpler. A sustained 10 second press of the button enters programming mode. Just tap the button once for each hour of run time you require, up to 24 hours. Programming mode expires 10 seconds after the last tap, and the unit then commits your settings to memory. If you happen to press the button more than 24 times, the maximum run time of 24 hours will be stored.

The HNS450TM is also equipped with Boost Mode, a convenient bonus feature that allows users to double the program run time (up to the maximum 24 hours). Instead of a quick tap, a sustained two second press of the button will initiate boost mode and the timer program will be automatically extended; for example, a 2-hour program would be extended to 4 hours.

2-in-1 power switch that automatically turns off after a programmable time
Time delay from 1-24 hours, in hour increments
Setting retained even after loss of power
Can power fans, motors, pumps, contactors and inductive loads

Warranty Information (From Install)

  • Commercial Use
  • Domestic Use
  • Warranty Method
  • Warranty Period

Attributes

  • Brand Cabac
  • Part Number - HNS450TM
  • Also Known As Mechanism
  • Amperage Range 5 Amps

Shipping Information

  • Freight Levy Freight Free on LED Couriers for orders over $500
  • Weight (kg) 0.0330
  • Length Packaging (mm) 70
  • Height Packaging (mm) 40
  • Width Packaging (mm) 70
  • Barcode 9318674090496
  • Barcode (Secondary) 9318674090502
