Victron QUATTRO 10kW 48/10000/140- 100/100 Inverter Charger

VICTRON 230V QUATTRO PURE SINE WAVE INVERTER / CHARGER VE BUS 48V 10000VA INVERTER 140A BATTERY CHARGER WITH 2x 100A AUTOMATIC TRANSFER SWITCH

Similar to the MultiPlus, the Quattro is also a combined inverter and charger. Additionally it can accept two AC inputs and automatically connect to the active source. Its many features include a true sine wave inverter, adaptive charging, hybrid PowerAssist technology plus multiple system integration features such as three or split phase operation and parallel operation.

The Quattro can be connected to two independent AC sources, for example shore-side power and a generator, or two generators. The Quattro will automatically connect to the active source. The main output has no-break functionality. In the event of a grid failure, or shore or generator power being disconnected, the Quattro takes over the supply to the connected loads. This happens so fast (less than 20 milliseconds) that computers and other electronic equipment will continue to operate without disruption. The second output is live only when AC is available on one of the inputs of the Quattro. Loads that should not discharge the battery, such as air-conditioning or a water heater can be connected to this output.


The Quattro will prevent overload of a limited AC source, such as a generator or shore power connection. First, battery charging will automatically be reduced when otherwise an overload would occur. The second level will boost the output of a generator or shore side supply with power taken from the battery.

Up to 6 Quattros can operate in parallel to achieve higher power output. Three phase or split phase operation is also possible. Please check our datasheets to see which models have paralleling, three phase and split phase capabilities.
Monitor and control your Quattro and system or systems' locally (LAN) or remotely via the internet from anywhere in the world, using the free VRM app and free VRM portal website. Access can be from a phone, tablet, laptop or PC for multiple operating systems. There is no end to the level of control, via the required Color Control GX or Venus GX, from adjusting your Quattro to setting a Geofence for hire vehicles and more...

Warranty Information:

Commercial Use 5 Years
Domestic Use 5 Years
Warranty Method Contact Victron Technician on 0413 339 140 or 0410 770 410 for Support
Warranty Period 5 Years

Attributes:

Brand Victron Energy
Part Number
QUA481030010

Shipping Information:

Attributes
Brand Victron Energy
Part Number
QUA481030010

Shipping Information
Weight (kg) 45.0000
Length (mm) 280
Height (mm) 470
Width (mm) 350
Length Packaging (mm) 350
Height Packaging (mm) 470
Width Packaging (mm) 280
Barcode 8719076024200
Barcode (Secondary) 8719076024200
