Reichle & De-Massari CAT6A 4 Pair Installation Cable U/FTP Shielded Grey 500 Metre Drum

Cat.6A, U/FTP cable. Foil shielding of pairs. 100 Ohm impedance. Data transmission frequencies of up to 650 MHz.

• Standardisation : ISO/IEC 11801 ed. 2.2; IEC 61156-5 2nd ed.; EN 50173-1; EN 50288-x-1; Fire rating: IEC 60332-1; IEC 60754-2; IEC 61034;
• Cable class : Installation Cable
• Category : Cat.6A ISO
• Cu cable shielding : U/FTP
• Number of fibres / conductors : 8
• Stranding : 4P
• Cable jacket material : LSZH
• Cable jacket characteristics : cable, metal-free ; zero-halogen ; flame-retardant
• Cable protection : no protection
• Cable overall diametre : nominal value ?? 7.1 - 7.6 mm
• Fiber / conductor diametre : AWG23
• Color code RAL : 7035
• Color : light gray

Warranty Information (From Install)

• Commercial Use ???? ????5 Years
• Domestic Use ???? ????5 Years
• Warranty Method ???? ????Return to All Led Direct
• Warranty Period ???? ????5 Years

Attributes

• Brand ???? ????Reichle & De-Massari
• Part Number???? ???? - R308247
• Also Known As ???? ????R+M cat6a shielded cable
• Cable Drum Length ???? ????500 Metres
• Cable Sheath Colour ???? ????Grey
• Category Type ???? ????CAT6A
• Data Cable Screening Type ???? ????U/FTP (Unshielded Foiled Twisted Pair)
• Data Cable Type ???? ????Shielded

Shipping Information

• Freight Levy ???? ????Freight Free on LED Couriers for orders over $500
• Weight (kg) ???? ????58.0000
• Length Packaging (mm) ???? ????400
• Height Packaging (mm) ???? ????330
• Width Packaging (mm) ???? ????400
• Barcode ???? ????2000100855768
