NHP Time Switch Digital Weekly 1 Channel 17.5mm 24VAC/DC

• Intelligent timing control of your loads to maximize efficiency and sustainability.
• Available in a weekly model for standard applications or weekly with astro functionality to capitalize on usage around sunrise and sunset times.
• Time switch models (35mm width) available with NFC communication capability. The NFC allows users to create/edit programs on their smartphones and tablets which can then be transferred seamlessly, securely, and wirelessly using NFC to the time switch unit. Using NFC, programs and values can also be read from time switch unit.
• The NFC time switch units are available in two programming modes, Smart and Classic!
• Simple selection of Australian daylight savings settings to ensure smooth transition and reliable operation all year round.

Warranty Information (From Install)

• Commercial Use 1 Year
• Domestic Use 1 Year
• Warranty Method Return to All Led Direct
• Warranty Period 1 Year

Attributes

• Brand NHP
• Part Number - DGT1024SLIM
• Also Known As timer NHPDGT1024SLIM
• Amperage Range 16 Amps
• Analog or Digital Digital
• Contact Configuration 1 x Changeover
• Cycle Weekly
• Number Of Contacts 1
• Number Of DIN Modules 1 Module
• Supply Failure Reserve Yes
• Time Increments 1 Minute
• Voltage 240 Volts

Shipping Information

• Freight Levy Freight Free on LED Couriers for orders over $500
• Weight (kg) 0.1400
• Length (mm) 63
• Height (mm) 90
• Width (mm) 18
• Length Packaging (mm) 110
• Height Packaging (mm) 90
• Width Packaging (mm) 45
• Barcode 8012823299068
• Barcode (Secondary) 2000100215418
