NHP 3.2 Amp - 16 Amp Electronic Overload Relay With Manual Reset

NHP 3.2 Amp - 16 Amp Electronic Overload Relay With Manual Reset

$127.99 AUD
$127.99 AUD $127.99 AUD
Sale Sold out
Tax included.
  • 5:1 wide current adjustment range to cover a variety of motor applications in a single device
  • Selectable Trip Class: Dip Switch Selection of trip class 10, 20 on Basic model or Dial Selection of trip class 10, 15, 20, 30 on Advanced mode
  • Accurate and repeatable settings to help minimise commissioning time
  • Higher efficiency and low heat dissipation versus traditional eutectic or bimetal relays
  • Pass-thru model minimises number of power terminal connections
  • Built-in thermal memory and phase loss detection helps protect your motor investment

Warranty Information (From Install)

  • Commercial Use 1 Year
  • Domestic Use 1 Year
  • Warranty Method Return to All Led Direct
  • Warranty Period 1 Year

Attributes

  • Brand NHP
  • Part Number - CEP71EEDB
  • Also Known As NHPCEP71EEDB
  • Amperage Range 3.2-16 Amps
  • Kilowatt Rating (kW) AC-3 1.5-7.5

Shipping Information

  • Freight Levy Freight Free on LED Couriers for orders over $500
  • Weight (kg) 0.3500
  • Length Packaging (mm) 138
  • Height Packaging (mm) 64
  • Width Packaging (mm) 110
  • Barcode 2000100851678
  • Barcode (Secondary) 00889508723075
