NHP 20 Amp MOD6 Miniature Circuit Breaker & Residual Current Device MCB/RCD RCBO C Curve 1 Pole 6kA 30mA

• Compact single screw RCBO (panelboard model and loadcentre) features earth reference lead ensuring correct operation in case of loss of neutral and a neutral pigtail saving cable and installation time
• Compact double screw RCBO (loadcentre model) easily combines with insulated busbar comb, eliminating any need for custom busbars and saving installation time
• MOD6 RCBOs feature 6kA short circuit rating
• 30mA sensitivity featured as standard on all MOD6 RCCBs and RCBOs simplifying the selection for general personnel protection applications

Warranty Information (From Install)

• Commercial Use 1 Year
• Domestic Use 1 Year
• Warranty Method Return to All Led Direct
• Warranty Period 1 Year

Attributes

• Brand NHP
• Part Number - MOD6RCBO12030AL
• Also Known As RCCB Residual Circuit Breaker Residual Circuit Breakers GFCI GFI ALCI RCD Safety Switch Safety Switches NHPMOD6RCBO12030AL
• Amperage Range 20 Amps
• Number Of DIN Modules 1 Module
• Poles 1 Pole
• Trip Current 6 kA
• Trip Curve C Curve
• Voltage 240 Volts

Shipping Information

• Freight Levy Freight Free on LED Couriers for orders over $500
• Weight (kg) 0.2458
• Length (mm) 76
• Height (mm) 125
• Width (mm) 18
• Length Packaging (mm) 138
• Height Packaging (mm) 40
• Width Packaging (mm) 80
• Barcode 9321807197719
• Barcode (Secondary) 5413656054481
